While everything stayed in the green during our tests, one thing we did notice is the 7,200RPM Constellation ES.3 HDDs Seagate includes with this unit did idle at a higher temperature that we would normally find in a NAS. The Seagate Business Storage WebGUI provides users with a wealth of information, including cooling performance. From out of the box to plugged in and sharing storage, it took us only 10-20 minutes. Seagate went to great lengths to make it easy for novice users to manage, while still including advanced features for the IT power user to customize the platform. Moving on to the Seagate web interface, we found it to be very intuitive and surprisingly pleasing to the eyes.
The chassis features a unique layered ventilation channel that allows small fans to regulate its temperature. The fans are also located inside and can be replaced with the same ease as the drives. Simply press the button and pop out one drive for another. The bays sit in two rows and are tool and cable free, and of course hot-swappable. Inside the Seagate Business Storage 8-Bay are 8 hot-swappable bays for 3.5″ drives. The right side includes vents for the fans.
#Seagate nas software serial
Going from left to right there are the PS/2 keyboard (bottom) and PS/2 mouse (top) ports, followed by 2 USB 2.0 ports, a Male DE-9 serial port, a VGA port, and 2 RJ45 ports. No tools are needed to swap out the power supplies, which is common on enterprise platforms. The rear of the Seagate Business Storage 8-bay NAS includes two hot-swappable power sources and plenty of connectivity. Heading from left to right there is a power button, a USB 2.0 port, 8 drive status lights, an ID button, and a mute button.Ī sliding rail kit is included and can be added to the sides along with a cable management arm that can keep everything organized. There are LED lights indicating drive status, power, mute, and ID. The front of the device is surprisingly compact given its total storage capacity and comparing it to NAS units with front-loading bays. The Seagate Business Storage 8-Bay is a 1U, 19″ Rackmount NAS. Dimensions (HxWxD): 43.5mm x 477mm x 772mm.Compatible Drives: 3.5-inch SATA II or SATA III.External Ports: 3 x USB 2.0 (1x front, 2x rear), 1 x VGA, 1x PS/2 keyboard, 1 x PS/2 mouse, Male DE-9 serial.
#Seagate nas software mac os
Client OS Supported: Windows 8, Windows 7, Windows Vista, Windows XP, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, & Mac OS 10.6 and later.Supports 10GBase-T, 100BASE-TX, and 1000BASE-T, RJ45 output.Included OS: Seagate NAS OS (embedded Linux).Processor: Dual-core 2.3GHz Intel 64-bit processor.Seagate Business Storage 8-Bay Rackmount NAS Specifications The Seagate Business Storage 8-Bay Rackmount NAS has a street price of $2,999.99 for the 8TB model running up to $5,099.99 for the 32TB model. It is more for smaller businesses (up to 100 employees) and has a storage capacity of 4TB to 16TB and runs from $1,128.99 to $2,299.99. The hot-swappable drives are removed through the front on the R4. It too is made with a compact design and a lot of power. Seagate also offers a 4-Bay Rackmount NAS. An LED lights lets you know if you are placing the drives in properly.
Using the sliding rail kit that is included, users can just pull out the R8, open it up, and press a button to swap out a drive, no cables or tools needed. And given that you can only fit four 3.5″ drives in a 19″ NAS, Seagate had to be innovative with their design. Most 4-bay models have the swappable drives that can be swapped from the front. The Seagate Business Storage 8-Bay Rackmount NAS is all about design, ease of use, and capacity. Running Seagate NAS OS, the R8 has multiple features including Wuala cloud service, centralized back-up for PCs and Time Machine support for Macs, and built in iSCSI. The R8 features a dual-core 2.3GHz Intel 64-bit processor and 4GB ECC DDR III of RAM for file transfer performance up to 200MB/s. This is the only 1U rackmount with 8 hot-swappable drives. The Seagate Business Storage 8-Bay Rackmount NAS is designed for small business with up to 250 employees that need high performance and capacity.
